实战 k8s里部署Grafna 2022.8.20(helm方式)(成功测试)

1实验环境：
21、win10,vmwrokstation虚机；
32、k8s集群：3台centos7.6 1810虚机，1个master节点,2个node节点
4   k8s version：v1.22.2
5   containerd://1.5.5

1[root@master1 vm-operator]#helm repo add grafana https://grafana.github.io/helm-charts
2"grafana" has been added to your repositories
3[root@master1 vm-operator]#helm repo update

 1cat <<EOF | helm install grafana grafana/grafana -f -
 2  datasources:
 3    datasources.yaml:
 4      apiVersion: 1
 5      datasources:
 6        - name: victoriametrics
 7          type: prometheus
 8          orgId: 1
 9          url: http://vmselect-vmcluster-demo.default.svc.cluster.local:8481/select/0/prometheus/
10          access: proxy
11          isDefault: true
12          updateIntervalSeconds: 10
13          editable: true
14
15  dashboardProviders:
16   dashboardproviders.yaml:
17     apiVersion: 1
18     providers:
19     - name: 'default'
20       orgId: 1
21       folder: ''
22       type: file
23       disableDeletion: true
24       editable: true
25       options:
26         path: /var/lib/grafana/dashboards/default
27
28  dashboards:
29    default:
30      victoriametrics:
31        gnetId: 11176
32        revision: 18
33        datasource: victoriametrics
34      vmagent:
35        gnetId: 12683
36        revision: 7
37        datasource: victoriametrics
38      kubernetes:
39        gnetId: 14205
40        revision: 1
41        datasource: victoriametrics
42EOF
43
44
45
46NAME: grafana
47LAST DEPLOYED: Tue May 17 17:13:14 2022
48NAMESPACE: default
49STATUS: deployed
50REVISION: 1
51NOTES:
521. Get your 'admin' user password by running:
53
54   kubectl get secret --namespace default grafana -o jsonpath="{.data.admin-password}" | base64 --decode ; echo
55
562. The Grafana server can be accessed via port 80 on the following DNS name from within your cluster:
57
58   grafana.default.svc.cluster.local
59
60   Get the Grafana URL to visit by running these commands in the same shell:
61
62     export POD_NAME=$(kubectl get pods --namespace default -l "app.kubernetes.io/name=grafana,app.kubernetes.io/instance=grafana" -o jsonpath="{.items[0].metadata.name}")
63     kubectl --namespace default port-forward $POD_NAME 3000
64
653. Login with the password from step 1 and the username: admin
66####################################################
67####   WARNING: Persistence is disabled!!! You will lose your data when   ####
68####            the Grafana pod is terminated.                            ####
69####################################################
70#本次log
71W0818 12:14:16.833439   52050 warnings.go:70] policy/v1beta1 PodSecurityPolicy is deprecated in v1.21+, unavailable in v1.25+
72W0818 12:14:16.835043   52050 warnings.go:70] policy/v1beta1 PodSecurityPolicy is deprecated in v1.21+, unavailable in v1.25+
73W0818 12:14:17.014946   52050 warnings.go:70] policy/v1beta1 PodSecurityPolicy is deprecated in v1.21+, unavailable in v1.25+
74W0818 12:14:17.015087   52050 warnings.go:70] policy/v1beta1 PodSecurityPolicy is deprecated in v1.21+, unavailable in v1.25+
75NAME: grafana
76LAST DEPLOYED: Thu Aug 18 12:14:16 2022
77NAMESPACE: default
78STATUS: deployed
79REVISION: 1
80NOTES:
811. Get your 'admin' user password by running:
82
83   kubectl get secret --namespace default grafana -o jsonpath="{.data.admin-password}" | base64 --decode ; echo
84
852. The Grafana server can be accessed via port 80 on the following DNS name from within your cluster:
86
87   grafana.default.svc.cluster.local
88
89   Get the Grafana URL to visit by running these commands in the same shell:
90
91     export POD_NAME=$(kubectl get pods --namespace default -l "app.kubernetes.io/name=grafana,app.kubernetes.io/instance=grafana" -o jsonpath="{.items[0].metadata.name}")
92     kubectl --namespace default port-forward $POD_NAME 3000
93
943. Login with the password from step 1 and the username: admin
95####################################################
96####   WARNING: Persistence is disabled!!! You will lose your data when   ####
97####            the Grafana pod is terminated.                            ####
98####################################################

 1👉 说明：
 2
 3```yaml
 4cat <<EOF | helm install grafana grafana/grafana -f -
 5  datasources:
 6    datasources.yaml:
 7      apiVersion: 1
 8      datasources:
 9        - name: victoriametrics
10          type: prometheus
11          orgId: 1
12          url: http://vmselect-vmcluster-demo.default.svc.cluster.local:8481/select/0/prometheus/ #这里是指定了grafna数据源的
13          access: proxy
14          isDefault: true
15          updateIntervalSeconds: 10
16          editable: true
17
18  dashboardProviders:
19   dashboardproviders.yaml: #个人对这个不是太清楚呀。。。
20     apiVersion: 1
21     providers:
22     - name: 'default'
23       orgId: 1
24       folder: ''
25       type: file
26       disableDeletion: true
27       editable: true
28       options:
29         path: /var/lib/grafana/dashboards/default
30
31  dashboards: #注意：这里是默认安装在grafna里的dashboard
32    default:
33      victoriametrics:
34        gnetId: 11176
35        revision: 18
36        datasource: victoriametrics
37      vmagent:
38        gnetId: 12683
39        revision: 7
40        datasource: victoriametrics
41      kubernetes:
42        gnetId: 14205
43        revision: 1
44        datasource: victoriametrics
45EOF

1☸ ➜ export POD_NAME=$(kubectl get pods --namespace default -l "app.kubernetes.io/name=grafana,app.kubernetes.io/instance=grafana" -o jsonpath="{.items[0].metadata.name}")
2     kubectl --namespace default port-forward $POD_NAME 3000
3Forwarding from 127.0.0.1:3000 -> 3000
4Forwarding from [::1]:3000 -> 3000

1[root@master1 ~]#kubectl get secret --namespace default grafana -o jsonpath="{.data.admin-password}" | base64 --decode ; echo
2GcVlzxMsneJoa8PDBeDMHHQmUeAfA9zAWRLmAM7i

1kubectl edit svc grafana
2……
3type: NodePort
4……
